Automated Crockery Sorting & Cleaning System
ACSCS
The Automated Crockery Sorting & Cleaning System (ACSCS) is a fully automated solution that streamlines crockery collection and pre-processing, eliminating the need for manual handling.
Designed with minimal human intervention in mind, ACSCS boosts efficiency and hygiene in high-traffic F&B environments. Each system offers tailored integration, with customizable machine flow to suit your location’s layout and ensure maximum user convenience.
01.
Robotic Arm Sorting System + Dish & Tray Washing Machine
Power: 139.1 KW
Dimensions:
9540mm × 4640mm (without turning conveyor line), 780mm (including turning line and connection cabinet) × 2300mm (including robot), 1800mm (excluding robot)
Weight: 4.3 tons
Inclusive of:
(a) Robotic Arm Sorting System + Dish & Tray Washing
Machine
(b) Rear-end Crockery
Sorting System
(c) AMR System
02.
Robotic Arm Sorting System + Dish & Tray Washing Machine
Power: 13 KW
Dimensions: 3845 x 2320 x 1670 mm
Weight: 2.4 tons
03.
Rear-end Crockery Sorting System
Power: 4.5 KW
Dimensions: 5430 x 2800 x 17800 mm
Weight: 1.2 tons
04.
AMR system
Power: DC 29 V, 6A
Dimensions: 710 x 500 x 310 mm
Weight: 60 KG
